130
Letter Fold-out
L2
L1
Paper feed direction
CEZ534
Double Parallel
L2
L1
Paper feed direction
CEZ536
Gate Fold
L3
L2
L1
Paper feed direction
CEZ537
The mark indicates the leading edge (relative to the paper feed direction), and
the mark indicates the trailing edge.
