Ricoh D296 - Page 344

Electrical Components
338
2. Disconnect the harness and remove the harness guide [A]. ( × 1, hook × 3)
• Release the harness guide [A] as shown below.
3. Remove the power pack (Development) [A] with the bracket. ( × 5, hook × 1)
4. Remove the power pack (Development) [A]. ( × 5, × 1)
