A153/A155/A156 EM 120K 240K 360K NOTE
Separation Torque Limiter
(LCT, By-pass feed)
R Clean with water. Replace
these rollers as a set.
Paper Feed Guide Plate C C C Alcohol
Relay rollers C C C Alcohol or water
Registration roller C C C Alcohol or water
Bottom Plate Pad (Paper
tray, By-pass feed, LCT)
CRRRWater
CLEANING UNIT
Drum Cleaning Blade R R R Spread setting powder. See
"Drum Cleaning Blade
Replacement".
Side Seal C C C Replace if necessary
Cleaning Entrance Seal C C C Replace if necessary
TRANSFER BELT UNIT
Transfer Belt C C R C Spread setting powder. "See
Transfer Belt Cleaning Blade
Replacement"
Transfer Belt Cleaning
Blade
CRRR
Used Toner Tank C C C Blower brush or vacuum
cleaner
FUSING UNIT
Fusing Entrance and Exit
Guide Plates
C C C Suitable solvent
Fusing Lamps I I I Replace if necessary
Hot Roller R R R
Pressure Roller C R C Suitable solvent
Fusing Thermistors C I I I Suitable solvent
Hot and Pressure Roller
Bearings
I I I Replace if necessary
Fusing Antistatic Brush I I I Replace if necessary
Cleaning Roller R R R Suitable solvent
Cleaning Roller Bushings I I I Replace if necessary
Fusing Exit Rollers C
Turn Guide Transport
Rollers
C
Hot Roller Strippers C R R R
DUPLEX TRAY
Clutch Spring L L L Mobil Temp 78. See Note 1.
Feed Roller R R R
Bottom Plate Pad R R R
Mylars I I I Replace if necessary
OTHERS
Drive Belts I I I Replace if necessary
FSM 4-55 FT5535/4527/4522
