3. If side-to side registration is not correct, go through the following steps:
1) Enter SP4-011.
2) Select the required 3rd level program number from the table below with the
and keys.
3rd Level Program Number Non-duplex Machines Duplex Machines
–001 1st Tray Duplex
–002 2nd Tray 1st Tray
–003 3rd Tray 2nd Tray
–004 4th Tray 3rd Tray
–005 5th Tray 4th Tray
–006 By-pass By-pass
–007 LCT LCT
–008 Base setting made in the factory
–009 ADF ADF
3) Change the side-to-side registration setting displayed in the reduce/enlarge
indicator. Use the number keys and follow these rules:
If the copy image is shifted to front, increase the setting
If the copy image is shifted to rear, decrease the setting
4) Leave SP mode.
5) Check whether side-to-side registration is correct or not. If it is not, repeat
the above steps from (1) to (4).
