5. SERVICE TABLES
5.1 DIP SWITCHES
DPS 101
Function
1 234
0000Normal setting
1000One-sided thin original mode free run with paper (35 cpm)
0100
One-sided thick original mode (normal mode) free run with
paper (35 cpm)
1100
One-sided thick original mode (normal mode) fee run without
paper (35 cpm)
0010Two-sided mode free run with paper (35 cpm)
1010Two-sided mode free run without paper (35 cpm)
1001One-sided thin original mode free run with paper (25 cpm)
0101
One-sided thick original mode (normal mode) free run with
paper (25 cpm)
0011Two-sided mode free run with paper (25 cpm)
1011Not used
1101Solenoid test
0110Motor test
1110Combine two originals mode free run with paper
0001Not used
0111Not used
1111Indicators On
NOTE: a) Paper will automatically feed after 3 seconds when the "with paper"
free run modes are selected.
b) To prevent the friction belt from wearing, open the feed-in cover when
performing the "without paper" free run modes.
c) The normal copying speed is 35 cpm for the A153/155/156, and 27
cpm for the A157/159/160.
To make a free run
1. Set up dip switches 1 to 4 for the required free run mode the test begins
automatically.
2. To stop the free run, put the dip switches back to 0.
FSM 7-7 FT5535/4527/4522
