6. REPLACEMENT AND ADJUSTMENT
6.1 STAPLER REMOVAL
1. Open the front door [A] of the sorter stapler and swing the staple unit [B] up.
2. Remove the staple unit cover [C] (1 screw).
3. Remove the stapler [D] (1 screw and 1 connector).
[A]
[B]
[C]
[D]
FSM 10-15 FT5535/4527/4522
