Ricoh FT5535 - Page 312

Component
(Symbol)
CN Condition
Symptom
At main sw power-up Ready condition
Bin-LED
(S5)
140-4
Open
(stays
Low)
The Sorter Jam indicator starts blinking when
sort/stack or staple mode is selected.
Shorted
(stays
High)
––
Bin-Photo.
Tr (S6)
≥ 4.0 V
≤ 1.0 V
155-3
Open
(stays
High)
–
Stapling does not occur
even though copying
has been completed in
staple mode.
Shorted
(stays
Low)
The Sorter Misfeed Location indicator starts
blinking when sort/stack or staple mode is
selected.
Grip H.P.
(S7)
≥ 4.0 V
≤ 1.0 V
115-2
Open
(stays
High)
The Sorter Jam
indicator starts blinking.
The Sorter Jam
indicator starts blinking
when copies are made
in sort/stack or staple
mode.
After the sorter stapler
or front door is
opened/closed, "SC
code (723)" will be
displayed.
Shorted
(stays
Low)
The grip motor keeps
rotating until the Sorter
Jam indicator starts
blinking.
The Sorter Jam
indicator starts blinking
when copies are made
in sort/stack or staple
mode.
After the sorter stapler
or front door is
opened/closed, "SC
code (723)" will be
displayed.
Bin H.P.
(S8)
≥ 4.0 V
≤ 1.0 V
130-11
Open
(stays
High)
––
Shorted
(stays
Low)
The Sorter Jam
indicator starts blinking.
–
Bin Exit (S9)
≥ 4.0 V
≤ 1.0 V
150-4
Open
(stays
High)
–
The Sorter Jam
indicator starts blinking
when copies are made
in sort/stack or staple
mode.
Shorted
(stays
Low)
The Sorter Jam
indicator starts blinking.
FT5535/4527/4522 10-30 FSM
