Ricoh FT5535 - Page 313

Component
(Symbol)
CN Condition
Symptom
At main sw power-up Ready condition
Proof Tray
Exit (S10)
≥ 4.0 V
≤ 1.0 V
150-7
Open
(stays
High)
–
The Sorter Jam
indicator starts blinking
when copies are made
in normal mode.
Shorted
(stays
Low)
The Sorter Jam
indicator starts blinking.
Roller Drive
Timing
(S11)
≥ 4.0 V
≤ 1.0 V
150-11
Open
(stays
High)
The Sorter Jam
indicator starts blinking.
The Sorter Jam
indicator starts blinking
or " SC code (720) " is
displayed when copies
are made.
Shorted
(stays
Low)
FSM 10-31 FT5535/4527/4522
