2.3.2 Paper Size Selection for Copier Paper Trays
For the 1st tray and 2nd tray for A153, A155, A157, and A159 copiers, and the
1st tray for A156 and A160 copiers, slide the paper size slider [A] to the paper
size indication that matches the paper size in the tray. The following paper sizes
can be selected with the paper size slider.
A4/A3 Version LT/DLT Version
A3 (lengthwise) 11" x 17"
B4 (lengthwise) 8
1/2" X 14"
A4 (lengthwise) 81/2" x 11"
A4 (sideways) 11" x 8
1/2"
B5 (lengthwise) A4 (lengthwise)
B5 (sideways) A4 (sideways)
A5 (sideways) 8
1/2" x 51/2"
8
1/2" x 11" 11" x 15"
11" x 8
1/2" 10" x 14"
11" x 17" F4 (8
1/2" x 13") (lengthwise)
F4 (8
1/2" x 13") (lengthwise) 8" x 10"
NOTE: For the 1st tray, a wider range of paper sizes can be selected with SP
mode. See section 2.3.4 and "Service Tables - SP5-019: Paper Size
Setting".
[A]
FT5535/4527/4522 3-14 FSM
