2.3.2 SP Mode Table
Mode No. Function Settings
1-001 Registration † Adjusts leading edge registration. 0 ~ 32
Default = 16 ‡
(0.5 mm per step [range: –8.0 mm to +8.0
mm])
1-003-001
to
1-003-008
Paper Feed
Timing †
Adjusts the paper feed timing at registration
for each paper feed station. Paper feed timing
is in proportion to the amount of paper
bending [mm] at registration.
0 ~ 32
Default = 16
SP1-003-008:
Do not adjust
this setting.
(1 mm per step [range: –16 mm to + 16 mm])
1-008 Misfeed
Detection †
Switches misfeed detection on or off for test
purposes (sensor signals are ignored). Only
one copy can be made at a time, to prevent
damage to the machine.
0: ON
1: OFF
1-103 Fusing Idling † Selects whether fusing idling is done or not.
Fusing idling lasts 2 minutes.
0: OFF
1: ON
After selecting ON or OFF, turn the main
switch off and on.
°1-104 Fusing
Temperature
Control †
Selects the fusing lamp temperature control
mode.
0: On/Off
Control
1: Phase Control
After selecting the control mode, turn the main
switch off and on.
1-105-001 Fusing
Temperature
Adjustment
(Main Fusing
Lamp) †
Adjusts the temperature of the main fusing
lamp, which heats the central area of the hot
roller.
The selected temperature is displayed in the
reduce/enlarge indicator.
170 ~ 190
Default = 180
(Type 1)
Default = 175
(Type 2)
(1°C per step [range: 170°C to 190°C])
SP Number
Without
Duplex
With
Duplex
SP1-003-001 1st tray Duplex
SP1-003-002 2nd tray 1st tray
SP1-003-003 3rd tray 2nd tray
SP1-003-004 4th tray 3rd tray
SP1-003-005 5th tray 4th tray
SP1-003-006 By-pass By-pass
SP1-003-007 LCT LCT
SP1-003-008 Japan only
Rev. 7/95
FSM 4-19 FT5535/4527/4522
