Mode No. Function Settings
1-105-002 Fusing
Temperature
Adjustment for
Energy Saver
Mode †
Adjusts the temperature of the main and
secondary fusing lamps in energy saver
mode.
(SP5-102 and SP5-305 are also related to
Energy Saver Mode.)
The lower the fusing temperature is, the
greater the energy saving ratio is and the
longer the waiting time until the copier returns
to the ready condition.
0 ~ 5
(Type 1)
0 ~ 4
(Type 2)
Default = 0
1-105-003 Fusing
Temperature
Adjustment
(Secondary
Fusing Lamp) †
Adjusts the temperature of the secondary
fusing lamp, which heats both ends of the hot
roller.
160 ~ 190
Default = 175
(1°C per step [range: 160°C to 190°C])
1-106 Fusing
Temperature
Display †
Displays the fusing temperature (°C) on the
surface of the central area of the hot roller, as
measured by the thermistor.
The temperature in energy saving mode
cannot be displayed, as entering SP mode
takes the machine out of this mode.
1-108 Forced Start † Selects whether forced start is on or off. 0: OFF
1: ON
If forced start is switched on, the copier enters
the ready condition even if the fusing
temperature has not reached the required
value yet. Use this for tests if the room
temperature is low and you do not wish to wait
for the lamps to warm up.
1-902 Jogger Span
Adjustment
(Side Fence) †
Adjusts the stop position of the jogger side
fence span of the duplex unit.
0 ~ 32
Default = 16
(0.5 mm per step [range: –8.0 mm to +8.0
mm])
A156 and A160 copiers only
1-905 Jogger Span
Adjustment
(End Fence) †
Adjusts the stop position of the jogger end
fence span of the duplex unit.
0 ~ 32
Default = 16
(0.5 mm per step [range: –8.0 mm to +8.0
mm])
A156 and A160 copiers only
SP Data Type 1 Type 2
0 175°C 175°C
1 160°C 150°C
2 145°C 125°C
3 130°C 100°C
4 115°C 75°C
5 95°C —
FT5535/4527/4522 4-20 FSM
