2.5 SP5-803 SENSOR/SWITCH INPUT CHECK
1. Access SP5-803 (refer to section 2.1).
2. Select the required 3rd level program number using the and
keys. See the following page for a list of which 3rd level number to use for
each component.
NOTE:
Do not press after selecting the 3rd level program number or
this SP mode will not operate.
3. If you want to check the signal during the copy cycle, enter the number of
copies in the copy counter and press the Start key.
4. The reading ("0" or "1") will be displayed in the reduce/enlarge indicator.
5. To check the reading from another sensor, switch, or signal, repeat from step
2.
3rd level
No.
Sensor/Switch/Signal
Reading
01
1 Upper Relay Sensor Paper not detected Paper detected
2 Lower Relay Feed Sensor Paper not detected Paper detected
3 3rd Tray Paper Feed Sensor
(Paper Tray Unit)
Paper not detected Paper detected
4 4th Tray Paper Feed Sensor
(Paper Tray Unit)
Paper not detected Paper detected
5 5th Tray Paper Feed Sensor
(Paper Tray Unit)
Paper not detected Paper detected
6 Registration Sensor Paper not detected Paper detected
7 Fusing Exit Sensor Paper not detected Paper detected
8 By-pass Feed Paper Width Sensor See the Note after the end of this table.
9 By-pass Feed Paper End Sensor Paper detected Paper not detected
10 By-pass Feed Table Switch Table is closed Table is open
11 Upper Tray Paper End Sensor Paper detected Paper not detected
12 Upper Tray Upper Limit Sensor Down Up
13 Not Used – –
14 Upper Tray Switch Not set Set
15 Lower Tray Paper End Sensor Paper detected Paper not detected
16 Lower Tray Upper Limit Sensor Down Up
17 Not Used – –
18 Lower Tray Switch Not set Set
19 1st Tray Paper End Sensor
(Paper Tray Unit)
Paper detected Paper not detected
20 1st Tray Upper Limit Sensor
(Paper Tray Unit)
Down Up
21 1st Tray Set Sensor
(Paper Tray Unit)
Not set Set
22 2nd Tray Paper End Sensor
(Paper Tray Unit)
Paper detected Paper not detected
23 2nd Tray Upper Limit Sensor
(Paper Tray Unit)
Down Up
Rev. 7/95
FSM 4-43 FT5535/4527/4522
