3rd level
No.
Sensor/Switch/Signal
Reading
01
24 2nd Tray Set Sensor
(Paper Tray Unit)
Not set Set
25 3rd Tray Paper End Sensor
(Paper Tray Unit)
Paper detected Paper not detected
26 3rd Tray Upper Limit Sensor
(Paper Tray Unit)
Down Up
27 3rd Tray Set Sensor
(Paper Tray Unit)
Not set Set
28 LCT Paper End Sensor Paper detected Paper not detected
29 LCT Upper Limit Sensor Off On
30 LCT Lower Limit Sensor Off On
31 LCT Connector Not connected Connected
32 LCT Tray Down Switch Off On
33 LCT Cover Switch Cover closed Cover open
34 Original Length Sensor 1 Off On
35 Original Width Sensor 3 Off On
36 Original Width Sensor 4 Off On
37 Original Width Sensor 5 Off On
38 Original Length (Optional) Sensor Off On
39 Original Length Sensor 2 Off On
40 Scanner H.P. Sensor Off On
41 Lens horizontal H.P. Sensor Off On
42 Lens vertical H.P. Sensor Off On
43 3rd scanner H.P. Sensor Off On
44 Optics Thermistor Off On
45 Platen Cover Close Sensor Platen cover open Platen cover closed
46 Platen Cover Open Sensor Platen cover closed Platen cover open
47 Vertical Guide Set Switch Vertical guide closed Vertical guide open
48 Paper Exit Cover Switch Paper exit cover
closed
Paper exit cover open
49 Front Cover Switch Front cover closed Front cover open
50 Sorter Entrance Sensor Off On
51 Sorter Bin H.P. Sensor Off On
52 Sorter Bin Lift Sensor Off On
53 Sorter Cover Switch Cover closed Cover open
56 Proof Tray Exit Sensor (A554 Sorter
Stapler Only)
Paper detected Paper not detected
57 Bin Exit Sensor (A554)/Sorter
Entrance Sensor (A555)
Paper detected Paper not detected
58 Bin Sensor (A554/A555) Off On
59 Bin H.P. Sensor Off On
60 Bin Lift Timing - 1 Sensor (A554)/
Wheel Sensor (A555)
Off On
61 Bin Lift Timing-2 Sensor (A554 only) Off On
63 Jogger H.P. Sensor (A554/A556) Off On
64 Grip H.P. Sensor (A554/A555) Off On
66 Staple H.P. (A554/A555) Off On
67 Staple End Switch Off On
68 Staple Paper Sensor Off On
69 Sorter Stapler Set SW. Front Door
SW (A554) Door Safety SW (A554)
Door Closed Door Open
Rev. 7/95
FT5535/4527/4522 4-44 FSM
