3rd level
No.
Sensor/Switch/Signal
Reading
01
70 Roller Drive Timing Sensor
(A554)/Timing Sensor (A554)
Off On
73 Duplex Entrance Sensor Off On
74 Duplex Turn Sensor Off On
75 Duplex Paper End Sensor Paper detected Paper not detected
76 Upper Tray Switch Not set Set
77 Duplex Side Fence Jogger H.P.
Sensor
Off On
78 Duplex End Fence Jogger H.P.
Sensor
Off On
80 Main Motor Lock Off On
81 Fusing Unit Set Sensor Not set Set
82 Transfer Belt Contact H.P. Sensor Off On
83 Toner End Sensor Toner remains Toner end
84 Key Counter Set Not set Set
85 Not Used – –
86 Total Counter On Off On
87 Auto Response Sensor Off On
90 ADF Original Width Sensor-3 Off On
91 ADF Original Width Sensor-2 Off On
92 ADF Original Width Sensor-1 Off On
93 ADF Registration Sensor Paper not detected Paper detected
94 ADF Feed Out Sensor Paper not detected Paper detected
95 ADF Position Sensor ADF closed ADF open
96 ADF APS Start Sensor On Off
97 ADF Feed In Cover Open Sensor Cover closed Cover open
98 ADF Feed Out Cover Open Sensor Cover closed Cover open
NOTE When SP5-803-008 (By-pass Feed Paper Width Sensor) is selected,
one of the following numbers will be displayed in the reduce/enlarge
indicator, depending on the by-pass feed side fence position.
A4/A3 Version
Side Fence Position Displayed Number
A3 7
11" 3
B4 11
A4 (lengthwise) 9
B5 (lengthwise) 13
A5 (lengthwise) 12
B6 (lengthwise) 14
LT/DLT Version
Side Fence Position Displayed Number
11" 3
8
1/2" 9
8" 13
5
1/2"14
FSM 4-45 FT5535/4527/4522
