Paper Size Mismatch (Tray 1)
● Pull tray 1 completely out. Take care not to drop it.
Remove loaded paper.
Squeeze the paper guides on both sides, and then adjust them according to the paper size.
● The front end paper guide may also need to be adjusted.
Load paper with the print side face down but not over the limit mark.
