Ricoh MP 3054 Series User Guide

8. Web Image Monitor
This chapter describes frequently used Web Image Monitor functions and operations. For information
not included in this chapter, see Connecting the Machine/ System Settings available on our website or
Web Image Monitor Help.
Displaying Top Page
This section explains the Top Page and how to display Web Image Monitor.
• When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10".
1. Start your web browser.
2. Enter "http://(machine's IP address or host name)/" in your web browser's URL bar.
Top Page of Web Image Monitor appears.
If the machine's host name has been registered on the DNS or WINS server, you can enter it.
When setting SSL, a protocol for encrypted communication, under environment which server
authentication is issued, enter "https://(machine's IP address or host name)/".
Web Image Monitor is divided into the following areas:
1
2
3
5
4
DDE001
1. Menu area
If you select a menu item, its content will be shown.
2. Header area
Display icons for the links to Help and the keyword search function. This area also displays [Login] and
[Logout], which allow you to switch between the administrator and guest mode.
157

Ricoh MP 3054 Series Specifications

General

Print Speed	30 ppm
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Monthly Duty Cycle	50, 000 pages
Maximum Paper Size	A3
Warm-up Time	20 seconds
Memory	2 GB RAM
Scan Resolution	600 dpi
Paper Capacity	4, 700 sheets
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Scan Speed	80 ipm (simplex)
Control Panel	Touchscreen
First Print Speed	4.6 seconds
Hard Disk Drive	320 GB
Fax Transmission Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 1200 dpi
