Ricoh MP 3054 Series User Manual

• The maximum number of sheets you can load at the same time depends on paper type. Do not
stack paper over the limit mark. For the maximum number of sheets you can load, see page 172
"Recommended Paper Sizes and Types".
1. Open the bypass tray.
DCG017
2. Load the paper face down until you hear the beep.
3. Align the paper guides to the paper size.
If the guides are not flush against the paper, images might be skewed or paper misfeeds might
occur.
DCG018
• When you use the bypass tray, it is recommended to load the paper in orientation.
• Certain types of paper might not be detected properly when placed on the bypass tray. If this
happens, remove the paper and place it on the bypass tray again.
• Pull the extender out when loading A4 , 8
1
/
2
× 11 or larger size paper in the bypass tray.
• When loading thick paper, thin paper, or OHP transparencies, specify the paper size and the
paper type.
• Letterhead paper must be loaded in a specific orientation. For details, see page 169 "Loading
Orientation-fixed Paper or Two-sided Paper".
Loading Paper
161

Ricoh MP 3054 Series Specifications

General

Print Speed	30 ppm
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Monthly Duty Cycle	50, 000 pages
Maximum Paper Size	A3
Warm-up Time	20 seconds
Memory	2 GB RAM
Scan Resolution	600 dpi
Paper Capacity	4, 700 sheets
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Scan Speed	80 ipm (simplex)
Control Panel	Touchscreen
First Print Speed	4.6 seconds
Hard Disk Drive	320 GB
Fax Transmission Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 1200 dpi
