Ricoh MP C6004 series User Manual

Step 3: Specifying access privileges for the created shared folder
If you want to specify access privileges for the created folder to allow other users or groups to access
the folder, configure the folder as follows:
1. Right-click the folder created in Step 2, and then click [Properties].
2. On the [Security] tab, click [Edit...].
3. Click [Add...].
4. In the [Select Users, Computers, Service Accounts, or Groups] window, click
[Advanced...].
5. Specify one or more object types, select a location, and then click [Find Now].
6. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
7. In the [Select Users, Computers, Service Accounts, or Groups] window, click [OK].
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Modify] check box.
9. Click [OK].
Registering an SMB Folder
1. Press [Home] ( ) at the bottom of the screen in the center.
2. Flick the screen to the left, and then press the [Address Book Management] icon.
3. Check that [Program / Change] is selected.
4. Press [New Program].
5. Press [Change] under "Name".
The name entry display appears.
6. Enter the name, and then press [OK].
7. Press [ Next].
Basic Procedure When Using Scan to Folder
135

Ricoh MP C6004 series Specifications

General

Print Speed (Black)	60 ppm
Print Speed (Color)	60 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed (Black)	60 ppm
Copy Speed (Color)	60 ppm
Copy Resolution	600 x 600 dpi
Fax Resolution	200 x 200 dpi
Duplex Printing	Yes
Automatic Document Feeder (ADF)	Yes
ADF Capacity	100 sheets
Memory (RAM)	2 GB
Hard Disk Drive	320 GB
Type	All in One Printer
Scan Resolution	600 dpi
Paper Capacity	4, 700 sheets
Standard Paper Capacity	1, 200 sheets
First Print Time (Color)	5.5 seconds
Connectivity	USB, Ethernet
PDL	PCL 5c, PCL 6, PostScript 3
