009
Displays data register value for
PIBEXINT
ENG
[0 to 255 / 0 / 1/step]
•
Bit 0: OPC Home Position
Sensor C (0: Not detected, 1:
Home Position detected)
• Bit 1: Development Sleeve
Home Position Sensor C (0:
Not detected, 1: Home Position
detected)
• Bit 2: OPC Home Position
Sensor Bk (0: Not detected, 1:
Home Position detected)
• Bit 3: Development Sleeve
Home Position Sensor Bk (0:
Not detected, 1: Home Position
detected)
• Bit 4: OPC Home Position
Sensor Y (0: Not detected, 1:
Home Position detected)
• Bit 5: Development Sleeve
Home Position Sensor Y (0:
Not detected, 1: Home Position
detected)
• Bit 6: OPC Home Position
Sensor M (0: Not detected, 1:
Home Position detected)
• Bit 7: Development Sleeve
Home Position Sensor M (0:
Not detected, 1: Home Position
detected)
PIB_VODKA Break in monitor.
7. Input and Output Check
676
