Ricoh MP C6502SP System Maintenance

010
FSBPort08 ENG
[0 to 255 / 0 / 1/step]
•
Bit 0: Not used
• Bit 1: Fusing Unit Specification
0 (Voltage 100V/200V) (0:
200V, 1: 100V)
• Bit 2: Not used
• Bit 3: Fusing Unit Specification
2 (Type) (0: Pro, 1: Office)
• Bit 4*: Fusing Unit
Specification 3 (Series 1/Unit
detection)
• Bit 5*: Fusing Unit
Specification4 (Series 2/ Unit
detection)
• Bit 6*: Fusing Unit
Specification5
• Bit 7: Not used
*Readings for bits 4, 5, 6:
Set: Bits 4, 5, 6 = “0”, “0”, “1”,
respectively
Unset: All other combinations
Displays data register value for FSB_VODKA Port08
Input Check Table
677
