11. NVRAM Data Upload/Download
Uploading Content of NVRAM to an SD card
Do the following procedure to upload SP code settings from NVRAM to an SD card.
• This data should always be uploaded to an SD card before the NVRAM is replaced.
• Make sure that the write protection of an SD card is unlocked
1. Do SP5990-001 (SMC Print) before you switch the machine off. You will need a record of the
NVRAM settings if the upload fails.
2. Switch the copier main power switch off.
3. Remove the SD slot cover [A] ( x 1).
4. Insert the SD card into SD card slot 2 (lower) [A]. Then switch the copier on.
5. Execute SP5824-001 (NVRAM Data Upload) and then press the “Execute” key.
6.
The following files are coped to an NVRAM folder on the SD card when the upload procedure is
finished. The file is saved to the path and the following filename:
855
