Ricoh MP C6502SP System Maintenance

2. Main SP Tables-4
SP4-XXX (Scanner)
4008
[Sub Scan Magnification Adj]
Adjusts Sub Scan Magnification by 0.1% each step.
001 - ENG
[-1.0 to 1.0 / 0.0 / 0.1 %/step]
Picture will stretch as value increases.
Picture will shrink as value decreases.
4010
[Sub Scan Registration Adj]
Adjusts Sub Scan Registration position of book scanner by 0.1mm each step.
001 - ENG
[-2.0 to 2.0 / 0.0 / 0.1 mm/step]
Picture will move to back edge of sub
scan as value increases.
Picture will move to front edge of sub
scan as value decreases.
4011
[Main Scan Reg]
Adjust Main Scan Registration position by 0.1mm each step.
001 - ENG
[-2.5 to 2.5 / 0.0 / 0.1 mm/step]
Picture moves to right as value
increases.
Picture moves to left as value
decreases.
91
