Windows Configuration
16
1
Windows 2000 / Windows NT 4.0:
A Open the [Printers] window from the [Start] menu.
B In the [Printers] window, click the icon of the printer you want to use. On
the [File] menu, click [Properties].
C On the [Ports] tab, click [Configure Port]
The [Port Configuration] dialog box appears.
Windows XP, Windows Server 2003:
A Open the [Printers and Faxes] window from the [Start] menu.
The [Printers and Faxes] window appears.
B Click the icon of the machine you want to use. On the [File] menu, click
[Properties]. The printer properties appear.
C Click the [Port] tab, and then click [Configure Port].
The [Port Configuration] dialog box appears.
• For TCP/IP, timeout setting can be configured.
• User, proxy, and timeout settings can be configured for IPP.
Reference
For information about these settings, see DeskTop Binder-SmartDevice-
Monitor for Client Help.
How to enable Recovery/Parallel Printing
If no settings on the
[
Recovery/Parallel Printing
]
tab are available, follow the procedure below.
A Start DeskTop Binder-SmartDeviceMonitor for Client, and then right-click
the DeskTop Binder-SmartDeviceMonitor for Client icon on the taskbar.
B Click [Extended Features Settings], and then select the [Set Recovery/Parallel
Printing for each port] check box.
C Click [OK] to close the [Extended Features Settings] dialog box
