Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[2 Holes Type JP / EU] 0.0 2.0 -2.0 0.5 mm
[3 Holes Type US]
[4 Holes Type EU]
[4 Holes Type NE]
[2 Holes Type US]
0402: [Adjust Punch Position With Feed Direction]
Adjust the horizontal position of the punch holes when using Finisher SR4090 or Finisher SR4100.
Press [+] to move the position toward the top edge (left) relative to the paper feed direction, or [−] to
move it toward the bottom edge (right).
