0504: [Paper Alignment for Stapling With Feed Direction]
Adjust the travel distance of the paper edge stopper for edge stapling in order to reduce horizontal
variation in paper alignment due to difference in size, thickness, and paper curl when using Finisher
SR4110.
Press [+] to increase the travel distance, or [−] to decrease.
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[A4 ] 0.0 5.0 -2.5 0.1 mm
[B5 JIS ] 0.0 1.0 -2.5 0.1 mm
[8
1
/
2
× 11 ] 0.0 5.0 -2.5 0.1 mm
[Other Paper Sizes] 0.0 5.0 -2.5 0.1 mm
0505: [Paper Alignment in Shift Tray Across Feed Direction]
Adjust the width of the paper alignment jogger in the shift tray in order to reduce vertical variation in
paper alignment due to difference in size, thickness, and paper curl when using Finisher SR4110.
Press [+] to make the width of the paper alignment jogger wider, or [−] to make narrower.
2. Details of Menu Items in Adjustment Settings for Skilled Operators
54
