7. Input and Output Check
Input Check Table
5803 [INPUT Check]
001
PIBPort07 ENG
[0 to 255 / 0 / 1/step]
•
Bit 0: ITB PP error detection K
(0: Normal, 1: SC detected)
• Bit 1: ITB PP error detection C
(0: Normal, 1: SC detected)
• Bit 2: ITB PP error detection M
(0: Normal, 1: SC detected)
• Bit 3: ITB PP error detection Y
(0: Normal, 1: SC detected)
• Bit 4: PTR PP error detection (0:
Normal, 1: SC detected)
• Bit 5: PTR separation PP error
detection (0: Normal, 1: SC
detected)
• Bit 6: PTR AC Error Detection
(0: Normal, 1: SC detected)
• Bit 7: Not used
Displays data register value for Displays data register value for PIB_VODKA Port07
