1. Main SP Tables-3
SP3-XXX (Process)
3011 [Manual ProCon :Exe]
001
Normal ProCon ENG
[- / - / -]
[Execute]
Executes Process Control
002
Density Adjustment ENG
[- / - / -]
[Execute]
Executes Density Adjustment Process Control.
003
ACC RunTime ProCon ENG
[- / - / -]
[Execute]
Executes ACC Run Time Process Control.
004
Full MUSIC ENG
[- / - / -]
[Execute]
Executes Process Control/Full MUSIC
005
Normal MUSIC ENG
[- / - / -]
[Execute]
Executes Process Control/Normal MUSIC.
3012
[ProCon OK?]
Displays result per color, from left 2 digits each, with order of YMCK.
*Refer below for result detail.
001
History:Latest *ENG [0 to 99999999 / 0 / 1/step]
Displays the latest Process Control execution result.
002
History:2Times Before *ENG [0 to 99999999 / 0 / 1/step]
Displays the second latest Process Control execution result.
