Output Check Table
5804
[Output Check]
-
080
Polygon Motor: KC ENG [0 or 1 / 0 / 1/step]
KC: Polygon OUTPUT Check
KC: Polygon ON for "1"
081
Polygon Motor: MY ENG [0 or 1 / 0 / 1/step]
MY: Polygon OUTPUT Check
MY: Polygon ON for "1"
202
Scananer Lamp ENG [0 or 1 / 0 / 1/step]
Executes OUTPUT Check for Scananer Lamp.
Used for checking the failure in Lamp when SC101-01, SC101-02, SC102-00,
SC142-00 occur.
220
LCT: Pickup SOL ENG [0 or 1 / 0 / 1/step]
Turns LCT Pickup SOL ON.
221
LCT:Feed Mtr:Feed
Speed2:550mm/sec
ENG [0 or 1 / 0 / 1/step]
Drives LCT Feed Motor at Feed Speed.
222
LCT:Feed Mtr:Feed
Speed1:352.8mm/sec
ENG [0 or 1 / 0 / 1/step]
Drives LCT Feed Motor at Process Speed.
223
LCT:Transport Mtr:Feed
Speed2:550mm/sec
ENG [0 or 1 / 0 / 1/step]
Drives LCT Transport Motor at Feed Speed.
234
LCT:Transport Mtr:Feed
Speed1:352.8mm/sec
ENG [0 or 1 / 0 / 1/step]
Drives LCT Transport Motor at Process Speed.
