Taurus-C1 Training
135
Slide 135
Outline of the Installation Procedure (1)
Do the following, with the machine's power off.
Unpack the Machine
» It is necessary to use a forklift to remove the machine
from its pallet.
Install the Attention Light
Install the Operation Panel
Connect the ARDF
» The ARDF is already installed when the machine leaves
the factory.
Attach the Fusing Roller Knob Holder
Level the Main Machine
» The leveling adjustments are very important. The level
of all the peripheral options (LCIT, Finisher, etc.) must
be adjusted to match the level adjustment of the main
machine.
Test the Breaker Switch
Install the Toner Bottles
This is an outline of the installation procedure. Important points will be mentioned
in the next few slides. See the service manual for full details.
To Next Page
