Skew and Registration Adjustment
After installation of each peripheral device, do some test
prints and check for the presence of skew, and check that
side-to-side registration is correct.
When you detect a problem with skew or side-to-side
registration, do the adjustment on the joint bracket
attached to the peripheral unit upstream of the unit where
the problem occurred.
Side-to-side registration is corrected by shifting the
upstream joint bracket left or right.
Skew is eliminated by inserting spacers (shims) under the
rear or front end of the joint bracket. These attached by
screws to the peripheral units before they leave the factory.
The locations of the spacers are shown in the service
manuals.
Before adjusting skew or registration manually,
be sure to enter the SP mode and set SP1206 to
"2" (OFF).
When you are finished, re-set SP1206 to "1".
