Magnification Correction (1)
During duplexing, some paper may shrink or swell after
going through the fusing unit on the first pass.
This small change in the paper size can cause inaccurate
registration on the 2nd side.
To adjust the magnification, use these SP modes:
2102-041: Side 1 main scan
2102-042: Side 1 sub scan
2102-043: Side 2 main scan
2102-044: Side 2 sub scan
Range: -0.8% to +0.8%
The above settings are used for all paper types except
custom paper types selected from the Paper Library.
See the next slide for the settings that are used with the
Paper Library.
