Taurus-C1 Training
45
Slide 45
Liquid Cooling System for Developer (1)
In addition to the air cooling ducts and fans, this machine has a liquid
cooling system for the developer in the PDCU.
The radiator cools the liquid, which is pumped to the development unit to
keep the temperature of the developer at the correct level.
Compared with an air cooling system, this system has two advantages.
It requires less space than an air cooling system.
A liquid cooling system makes it possible to maximize operation time,
because the machine does not need to stop temporarily for a PCDU to
cool if temperature becomes too high.
Developer
Pump
Pipe
Radiator
This is the first time that a liquid cooling system has been used in a digital cut-
sheet product.
