Ricoh PRO C751 - Page 46

Taurus-C1 Training
46
Slide 46
Liquid Cooling System for Developer (2)
 Liquid coolant is pumped
from a tank [1] and circulated
through the jackets of the
development units through
two hoses [2].
 The rubber tubing is
guaranteed for 20 years of
use at 70°C (158°F).
 Rate of evaporation of
coolant:
 150 cc/7 years at 32°C
(90°F) running 24
hours/day with FC
duplexing.
 86 cc/7 years at 25°C
(77°F) running 24
hours/day with FC
duplexing.
