Taurus-C1 Training
70
Slide 70
Fusing Belt Cleaning
There is no fusing belt cleaning roller. The
cleaning fabric touches the surface of the
pressure roller directly.
There is no oil supply mechanism for lubricating
the fusing belt in this machine.
In this machine, the web end sensor of the fusing
cleaning unit is a photo-sensor. It signals web
end when it can no longer detect the surface of
the fabric. This is a much simpler design.
The fusing cleaning unit of previous machines had a fusing belt cleaning roller
between the fusing belt and the cleaning fabric. The roller scavenged toner, dust,
etc. from the surface of the fusing belt.
