Ricoh SP 5310DN User Manual

Lower the "C" lever and
pull out the jammed
paper carefully.
Open the rear cover.
Pull the tray carefully
until it stops, lift the
front side of the tray,
and then pull it out of
the printer.
Lower the "Z" lever
and pull out the
jammed paper
carefully.
Lift the "Z" lever.
DPL055
• When closing the front cover, push the upper side of the cover firmly. After closing the cover, check
that the paper jam is cleared.
• If paper misfeed message (B) appears, carefully remove jammed paper from behind the
registration roller.
DPL050
• If a paper misfeed occurs, remove paper left in the machine or caught among parts of the machine.
Removing Jammed Paper
111

Ricoh SP 5310DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.2, PDF 1.3, PDF 1.4, PDF 1.5, PDF 1.6, PDF 1.7, PDF 1.7+, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (printing)	- W
Total input capacity	- sheets
Maximum input capacity	2600 sheets
Processor family	Intel® Celeron®
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper, Transparencies
Paper tray media weight	64 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Network ready	-
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Product color	White
Cables included	AC

Weight and Dimensions

Depth	410 mm
Width	420 mm
Height	345 mm
