32DSSS01.A
1-
TABLE 1-1: S-SERIES LIFT TERMINOLOGY
REF NAME DESCRIPTION
1 Left
Position references when lift is viewed from outside of
vehicle.
2 Right
3 Front
4 Rear
5 Hydraulic Cylinder
(Left and Right) Telescoping steel tube, which converts
hydraulic pressure into lifting force.
6
Hydraulic Power
Unit
Contains pump used to create hydraulic pressure to raise
and fold lift, as well as a valve to unfold and lower lift.
7
Manual Backup
Pump Handle
Used to operate manual back up-pump when electrical
power is not functional.
8 Baseplate Assembly
Assembly that bolts securely to vehicle floor.
9
Serial Number
Location
Location of serial number decal.
10 Top/Bottom Arms
(Left/Right) Upper and lower links connecting vertical
arm to base assembly.
11 Vertical Arm (Left/Right) Connects platform and top/bottom arms.
12 Handrail (Left/Right) Provide hand-holds for platform occupant.
13 Control Pendant Hand-held device used to control lift functions.
14 Front Rollstop
Front barrier prevents wheelchair from slow, inadvertent
rolling off of platform during lift operation.
15 Platform
Component of lift where wheelchair and occupant sit dur-
ing "Up" and "Down" operations.
16
Bridgeplate
(Inboard Rollstop)
Barrier to prevent wheelchair from rolling off of platform
during lift operation.
17
Occupant Restraint
Belt
Electrically interlocked safety belt that is intended to pre-
vent acceleration of wheelchair from platform. Lift will
not operate unless belt is properly engaged.
END OF TABLE
