32DSSS01.A
2-
II. S-SERIES TRANSIT USE (ADA) OPERATING INSTRUCTIONS
his chapter contains safety precautions, daily safety check instructions, control and indicator
descriptions and operating instructions for the RICON S-Series (ADA) Transit Use Wheelchair
and Standee Lift. This chapter must be thoroughly understood before attempting to use the lift.
A. SAFETY PRECAUTIONS
The following safety precautions must be complied with when operating lift:
§ Refer to Figure 2-1. Deploying lift when vehicle is on sloped ground is danger-
ous. Always operate lift with vehicle parked on level ground.
§ Vehicle must be safely parked with the emergency
brake ON before using lift.
§ Inspect lift prior to each use. DO NOT use if any un-
safe condition exists or unusual noises or movements
are noticed, and contact a Ricon authorized service
technician for repair.
§ Read and comply with all warning labels and symbols
affixed to wheelchair lift.
§ Refer to Figure 2-2. Wheelchair occupant should
FACE OUTWARD when entering or exiting vehicle.
§ Standees should use lift facing the direction of travel;
toward vehicle when entering or away from vehicle
when exiting.
§ Do not rely on an audible threshold warning device to
provide assurance that it is safe to exit the vehicle fac-
ing backwards. This device may be inoperative or un-
heard, and you might exit backwards when the plat-
form is on the ground! Exit facing outward, and be
certain the platform is at floor level.
§ Do not back onto platform when exiting vehicle. Face
OUTWARD, if possible, and make sure that platform
is at a safe vehicle floor-level position, and outer roll-
stop is up and locked.
FIGURE 2-2: FACE
OUTWARD
