Ricon S Series Operator's Manual

32DSSS01.A
2-
3
C. LIFT FUNCTIONS
TABLE 2-1: LIFT FUNCTIONS
FUNCTION DESCRIPTION
DEPLOY
Platform unfolds/deploys out of vehicle from stowed
position. (If equipped with a Ricon power door opera-
tor, the doors automatically open before lift deploys.)
DOWN
Platform is lowered from vehicle floor level position to
ground level. (The rollstop automatically lowers when
platform reaches ground level.)
UP
Platform is raised from ground level to vehicle floor
level. (The rollstop automat
ically rises when platform
leaves ground level).
STOW
Platform folds/stows from vehicle floor level to stowed
position. (If equipped with a Ricon power door opera-
tor, the doors automatically close after lift stows.)
END OF TABLE
NOTE: The up and down functions do not operate if platform is stowed.
FIGURE 2-4: PLATFORM POSITIONS
