Maintenance RLD motor gearboxes
Inspection and maintenance work is only permitted to approved personnel.
Maintenance RLD80/200 [0-10 V/Modbus]
Maintenance on the RLD motor gearbox is usually not necessary ("maintenance-free"). It is
recommended to do the checks that follow every 6 months:
● Of the correct operation of the drive unit and the system
● For a satisfactory view of possible malfunctions and easy access to all LEDs
● For error-message indications of the blink codes
● For oil leakage. Tell your installer if there is a leakage
● Of the mechanical condition (wear and tear, output-shaft connections to the operated system,
fasteners, correctly attached and such)
● Of the set end positions (are they still correct for the system?)
● Of the set emergency position (if applicable)
● The operation of the emergency power supply (if applicable).
Maintenance RW motor-gearboxes
Inspection and maintenance work is only permitted to approved personnel.
Maintenance on the RW motor-gearbox is usually not necessary ("maintenance-free").
Maintenance RW45
It is recommended to do the checks that follow every 6 months:
● Of the correct operation of the drive unit and the system
● For grease leakage. Tell your installer if there is a leakage
● Of the mechanical condition (wear and tear, output-shaft connections to the operated system,
fasteners, correctly attached and such)
● Of the adjusted end positions (are they still correct for the system?).
Maintenance RW240/400/600 - RW800 - RW1000/1200/1400/1600/2000 - RW70/100/140/200
Installation:
After installation interchange the plug in the highest position with the vent plug!
It is recommended to do the checks that follow every 6 months:
● Of the correct operation of the drive unit and the system
● For oil leakage. Tell your installer if there is a leakage
● Of the mechanical condition (wear and tear, output-shaft connections to the operated system,
fasteners, correctly attached and such)
● Of the adjusted end positions (are they still correct for the system?).
