Ride1up CORE-5 - Table of Contents

For the most up to date documents, bike models, additional information, instructional videos,
And more visit us at Ride1UP.com
3
Model: Core-5
Table of Contents
1. Safety Notes 4
1.1) Personal Safety 4
1.2) E-bike Safety 4
1.3) Electrical Safety 4
1.4) Brake Safety 4
1.5) Maintenance 5
1.6) Additional Warnings 5
2. Installation Steps: Assembling Your Bike 7
2.1) Fork/Headset Assembly 7
2.2) Front Wheel Assembly 8
2.3) Seat Post Assembly 9
2.4) Seat Clamp Assembly 10
2.5) Pedal Assembly 10
2.6) Detailed Torque Settings 11
2.7) Adjust Derailleur and Shifter 11
2.8) Test and Adjust Front and Rear Brakes 12
2.9) Spoke Tension 12
3. Battery Connection & Removal 12
4. Charging the Battery 12-14
5. Display Instructions 14
6. Common Assembly/Unboxing Issues: 14
6.1) Fork/Headset 15
6.2) Bent Derailleur Hanger 15
7. Error Code Troubleshooting 16
7.1) Error Codes/Source of the Error 16
8. Warranty Information 17
8.1) How to Handle Warranty Claim
