cut pipe up to 6" nominal diameter, and with the addition of
one chain extension can cut pipe up to 8" nominal diam-
eter.
See the Soil Pipe Cutter Capacity Chart
for specific in-
formation on the types of material and sizes cut with
each.
Soil Pipe Cutter Capacity Chart
226 In-Place Soil Pipe Cutter
Figure 1 – 226 Soil Pipe Cutter
The RIDGID 226 In-Place Soil Pipe Cutter is a compact
tool (17" long) designed to cut hub and no-hub soil pipe,
especially where space is limited. The handle is removable
to allow use in tight spaces. The feedscrew is equipped
with a hand knob for fast adjustment, and a 15" long
1
/
2
"
drive ratchet is supplied for operation. If needed, the 226
can also be operated with any
1
/
2
" drive ratchet or
15
/
16
"
wrench. The 226 uses a unique hooking mechanism to
make hooking the chain easier.
The 226 In-Place Soil Pipe Cutter is protected under var-
ious U.S. and International patents, including U.S. Patent
6,141,876.
Soil Pipe Cutters
Ridge Tool Company
2
206 and 246 Soil Pipe Cutters
Figure 2 – 206/246 Soil Pipe Cutter
The RIDGID 206 and 246 Soil Pipe Cutters utilize an inte-
gral ratchet handle centered on the pipe. This is espe-
cially useful when cutting pipe in trenches, and helps keep
the width of the trench to a minimum. Both use a unique
hooking mechanism to make hooking the chain easier.
The 206 uses the same chain as the 226 and 276, while
the chain on the 246 is larger and allows it to cut 4" class 22
water main and 2" – 5" extra heavy duty soil pipe.
276 Soil Pipe Cutter
Figure 3 – 276 Soil Pipe Cutter
The RIDGID 276 Soil Pipe Cutter is designed to allow soil
pipe to be cut in a single stroke. This allows repeated
cuts to be made quickly.
Model Material/Size
226 206 276 246
*
(1)
*
(1)
*
(1)
*
(1)
Clay pipe, 8"
* * * * Service weight cast iron solid pipe, 8"
* * * * No hub cast iron soil pipe, 8"
• • • • Concrete pipe, 4" - 6"
• • • • Clay pipe, 1
1
⁄
2
" - 6"
• Class 22 water main, 4"
• Extra heavy-duty cast iron soil pipe, 2" - 5"
• • • • Service weight cast iron soil pipe, 1
1
⁄
2
" - 6"
• • • • No hub cast iron soil pipe, 1
1
⁄
2
" - 6"
• Standard Length Chain. *Chain with One Chain Extension.
(1) Up to 15" Clay Pipe only can be cut with extended chain.
