RIDGID JP0610 - Repair Parts - Figure 5; Parts List for Figure 5

43
Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06101
RIDGID parts are available on-line at www.ridgidparts.com
Figure 5
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
13
14
15
17
19
18
1
2
3
4
5
7
6
12
8
9
10
11
16
20
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
826122
826123
817357-5
826395
808275-4
138164
826653
805475
824914
169123-15
Key Switch
Switch Locking
* Screw Ty AB M4 x 1.6-18
Bezel Switch
* Screw Pan Hd #8-32 x 3/8
* Lockwasher #8
Plate Switch Bezel
* Nut #8-32
Box Switch
Strain Relief 6P3-4
Key
No.
Part No. Description
11
12
13
14
15
16
17
18
19
20
824911-1
817393-7
818654-8
824931
160033-1
828530
827642-1
824915-1
69164
826817-1
Cord w/Plug
V-Belt A-36
Key
Pulley
Screw Set 1/4-20 x 3/8
Motor
* Bolt Rd Hd Sh 5/16-18 x 1/2
Cord Motor
Strain Relief 6N3-4
Nut
