RIDGID R4850 - Functional Description; Foreword; Motor Specifications

2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ...................2
FUNCTIONAL DESCRIPTION
.................................2
FEATURES ..............................................................3
SAFETY GUIDELINES - DEFINITIONS ...................4
GENERAL SAFETY RULES .......................................5
ADDITIONAL SPECIFIC SAFETY RULES ................ 6
PROPOSITION 65 WARNING ................................6
UNPACKING
..........................................................8
ASSEMBLY
.............................................................9
OPERATION
.........................................................11
MAINTENANCE/ADJUSTMENT .............................15
TROUBLESHOOTING ............................................19
ACCESSORIES
......................................................19
PARTS, SERVICE OR WARRANTY ASSISTANCE ...20
FOREWORD
The RIDGID® Model R4850 is a 13 inch (330mm) Portable Planer
that has a cutting capacity of 13 inch (330mm) wide, 6 inch
(152mm) thick and 1/8 inch (3.2mm) deep. This machine has a
powerful 15 amp 120 volt motor with a three-knife cutterhead.
FUNCTIONAL DESCRIPTION
NOTICE: The cover illustration shows the current production
model configuration. All other illustrations contained in the
manual are representative only and may not depict the actual
labeling or accessories included. These are intended to illustrate
technique only.
MOTOR SPECIFICATIONS
Your machine is wired for 120 volt, 60 Hz alternating current.
Before connecting the machine to the power source, make sure
the switch is in the “OFF” position.
Specications:
Model: R4850
Supply Voltage: 120 V AC~
Current: 15 A
Frequency: 60 Hz
No Load RPM: 10,000/min
