3. TECHNICAL DATA
3. Technical Data
ENGLISH
Type Cooling system 12 kW Cooling System 17 kW
GDD part number 2NK6 746W 2NK6 745-1W
Siemens part number 10589726 10430821
Net cooling capacity 12 kW 17 kW
Voltage
Max. current consumption 19A 23A
Max. electr. power input (50Hz) 10kW 12 kW
Max. electr. power input (60Hz) 13 kW 15 kW
Weight 410 Kg 413 Kg
Rated flow rate, primary circuit
Rated flow rate, secondary circuit
Rated temperature, secondary circuit
Outside temperatures
Outside temperatures with flow heater
Installation area volume, indoor Unit
Maximum installation height:
Maximum operating pressure against closed slide valve
(primary and secondary circuits)
3x 400V/50Hz / 3x 460-480V/60Hz
2.7 m³/h
2.5 m³/h
3.8 – 4.0 bar
(Pressure can be read off the pressure gauge on the unit)
min. 12m³
2000 m
(3000 m at max. ambient temperature of 40°C)
14 °C +1K / -2K
-30°C to +50°C
-40°C to +50°C
