Bolero 2.0 User Manual
3.3.6.7 Service
Test
Walk Test
Analyzes the signal quality to the visible Antennas. Following
values are shown:
· Antenna ID
· Antenna RPN
· current Signal Strength
· current Signal Quality
Walk Test Pro
Lists all Antennas that are visible at the current position. Following
values are displayed:
· Antenna ID
· Antenna RPN
· Signal strength
· Busy: available Antenna capacity (ok, full)
· CRC errors downlink
· CRC errors uplink
Reset
Profile Defaults
Resets the profile to default values.
All individual changes will be reset.
All registration data stays in memory.
Factory Reset
Resets the Beltpack to factory default settings.
All data (Net lists, Profiles, Registrations) will be lost! A new
registration is required.
Information
Radio
Displays a table with radio information.
Following values are displayed:
· Visible Antennas
· Actual Radio Level
· Radio Quality
· Antenna Name
· Antenna Number
Beltpack
Displays a table with Beltpack information.
Following values are displayed:
· Package Version: x.x.x
· Firmware Version: Vxx.xx.xx
· Hardware-Revision: xx.xx
· Main Version: xxx
· Display Version: xxx
· Serial number: (13 digits)
Battery
Displays a table with Battery information.
Following values are displayed:
· Charge Status: xx %, xxxx mAh
· Charge Mode:(not charging, xxxx mA
· Temperature: (too cold!, cold, normal, warm, too hot!)
· Battery Health: xxx % of max. capacity
· Capacity Max.: xxxx mAh
· Hardware: xx.xx
· Serial Number: (13 digits)
Area
Protected menu – for Riedel service purpose only
