Bolero 2.0 User Manual
4.4.2.2 Edit (Antennas)
Clicking the Edit symbol opens a dialog to edit Antenna (device) settings.
The dialog can be closed by pressing the ESC key without saving any changes.
Apply
Stores all changes.
Cancel
Discards all changes.
Figure 125: Edit (Antennas)
Name
Name of the Antenna.
User ID
Unique ID of the Antenna.
Antenna RF
Enabling/Disabling the radio of the Antenna.
IP Address Mode
Selection of the IP address mode (Auto, DHCP, Static).
Static IP Address
*1
Fixed IP address of the Antenna.
Subnet Mask
*1
Fixed subnet mask of the Antenna.
Static Gateway
*1
Fixed Gateway of the Antenna.
PTP Master Priority
Selection of the PTP priority (default: 124).
Sync Master Priority
Defines the priority of a node becoming sync master for the entire system.
*1
if IP Address Mode = Static
'Standalone/Link' mode only
