Technical description of the burner
4.5 Maximum dimensions
The maximum dimensions of the flange and burner are given in Fig. 1.
Tab. D
4.6 Firing rate (as EN 267)
CFG
130
I
45
ø
E
A
11
D
180
72 72
150
45
ø H
B
°
°
Fig. 1
Flange Burner
D5305
Model A B C D E F G H I
RIELLO 40 G5 BF 271 249 288 191 90 93 226 75 26
0.8
0
0.4
2 2.5 3
20 4025 30 35
0.2
0.6
1.5 3.5
Fig. 2
Pressure in the combustion
chamber – mbar
Fuel output - kg/h
Thermal power - kW
