INSTALLATION
33
CONDEXA HPR 35-45
CONDEXA HPR 55-70
0
2
4
6
8
10
12
14
16
18
20
22
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
HPR 55
HPR 70
Flue gas pipe length (m)
Air suc�on pipe length (m)
MAX LENGTH PIPES Ø80 + Ø80 CONDEXA HPR
CONDEXA HPR 35-45
− Make sure the 4 tabs (A) are inserted in the groove
(B).
− Fully tighten the screws (C) that hold the two lock-
ing terminals of the ange, so the bend is held
against the ange itself.
Ø 80-125 Ø 60-100B23P-B53P Ø 80-80
B
C
C
A
A
CONDEXA HPR 35-45
Ø 80-125
B23P-B53P
Ø 80-80
CONDEXA HPR 55-70
0
5
10
15
20
25
30
35
40
45
50
55
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75
Flue gas pipe length (m)
Air suc�on pipe length (m)
MAX LENGTH PIPES Ø80 + Ø80 CONDEXA HPR
HPR 45
HPR 35
CONDEXA HPR 35-45
B23P - B53P Ø60-100
Ø80-125
Ø80-80
Ø80-80
with adaptor
CONDEXA HPR 55-70
B23P - B53P
Ø80-80
with adaptor
See info at
Ø80-125 curve installation
paragraph
Ø80-125
