ENGLISH
8
PHISICAL INSTALLATION OF THE DEVICE
This device can be installed on a DIN (see Picture 8, Picture 9 and Picture 10) rail or wall-
mounted (Picture 11).
12
3
1. Bolt
2. Washers
3. Nut
Picture 8 assemble bolt Picture 9 lift the wings by means of a flat
screw driver
Picture 10 hang the device on a DIN rail and
screw the bolts to secure the case to the rail
Picture 11 Drill template for wall-mount (dimensions in mm)
