Technical description of the burner
5.8 Electrical panel description
1 Ignition transformer
2 A switch for:
automatic-manual-OFF operation
A button for:
increase - decrease output
3 Motor contactor and thermal relay with reset button
4 Terminal board for electrical connection
5 Cable-grommets for external connections to be carried out
by the installer
6 Control box base
7 Flame sensor
8 Coil for oil valves
Fig. 5
2
3 1
7
6
8
5
4
